40-6902
Johnson Level 22X Builder's Level - 40-6902
In stock
Horizontal circle – graduated to single degrees and reads by vernier direct to 15 minutes
- Horizontal circle – graduated to single degrees and reads by vernier direct to 15 minutes
- Horizontal tangent screw – for precise movement control
- Built-in sunshade – for clear sighting
- Top mounted leveling vial – for effortless viewing
- Large leveling screws – easy to turn
- Versatile – ideal for leveling foundations, driveways, patios, floors, for grading street, curbs and ditches, for aligning fences; or any other light construction job
Johnson's 40-6900 22X Builder's Level Includes:
- Builder's level
- Instruction manual with warranty card
- Hard-shell carrying case
|
General
|
|
| Weight | 2.20 lbs (1kg) |
| Warranty | 1-year |
| Tripod Thread | 5/8 x 11 |
|
Distance Measurement
|
|
| Range | 200 ft |
| Leveling Accuracy | 3/16-inch at 100 feet |
|
Angle Measurement
|
|
| Horizontal Circle | 15-minute |
|
Telescope
|
|
| Magnification | 22x |
| Minimum Focus Distance | 4 ft |
| Objective Aperture | 22 mm |
| Stadia Lines | yes |
| Image | Erect |
|
Features
|
|
| Bubble Vial Level | yes |
| Adjustment Knobs | yes |
| Sunshade | Built-in |
|
Applications
|
|
| Turn and Measure Angles | yes |
| Leveling Forms and Footers | yes |
| General Landscaping | yes |
| Manufacturer | Johnson Level |
|---|
