LL100N
Spectra Precision LL100N Self Leveling Laser
In stock
Special Price
$675.00
Regular Price
$750.00
The Spectra Precision® Laser LL100 is a complete one man leveling crew in a case.
A leveling crew in a case for the small contractor
The Spectra Precision® Laser LL100N is a complete one man leveling crew in a case. A complete system is contained in a single hard-shelled, portable carrying case - the laser, receiver, clamp, tripod, and grade rod - for easy transportation, storage, and use. A standard case with laser and receiver only is also available. Automatic, self-leveling ensures fast, accurate setups. Easy, one-button operation requires minimal training.The LL100N laser is capable of handling a wide variety of elevation control applications. Versatility is added with single-axis manual slope capability for setting out driveways, ramps, and residential drainage lines. It is rugged enough for the toughest jobsite and designed to survive a 3 foot (1 m) drop onto concrete. The LL100N is backed by a 3-year instant over the counter exchange warranty.
Features & Benefits:
- Automatic self-leveling increases productivity with fast setups and minimal training
- One person elevation control up to 1150 ft (350 m) away increases productivity
- Durable construction can withstand tough jobsite conditions
- Height of Instrument alert stops laser rotation if elevation changes occur to avoid erroneous readings
- HR320 receiver offers 2 accuracies and has grade displays front and rear
- Exclusive 3-year limited warranty with instant "over the counter" exchange policy eliminates downtime
Applications:
- General elevation control
- Checking and setting elevations for smaller jobsites
- Leveling forms and footers
- Estimating cuts and fills
- Ideal for decks, terraces, pools, and septic systems
- Basic slopes for driveways, ramps, and residential drainage
Leveling Type | Automatic (electronic) |
Horizontal Leveling | Yes |
Vertical Leveling | Yes |
Accuracy | ±1/8 in. @ 100 ft. |
Rotation Speed | 600 RPM |
Beam Type | Single |
Laser Beam Color | Red |
Exterior Range (ft.) | 1,000 |
Grade Capability | Single-axis manual slope |
Laser Output | 650 nm |
Leveling Range | 150ft. |
Self Leveling Range | ±5° |
Visual or Audible Indicator | Visual, audible |
Indicator Type | LCD display |
Working Temperature | 23 to 113 degrees fahrenheit |
Battery Type | D |
Battery Included | Yes |
Battery Life | 80 hrs. |
Single, Pair, or Set | Set |
Tripod Mount Dimensions (in.) | 5/8–11 |
Class Rating | Class II |
Case Type | Hard shell case |
Manufacturer | Spectra Precision |
---|---|
Max Rotating Speed | 600 rpm |
Laser Orientation | Horizontal & Vertical |
Laser Range | 50 ft +, 100 ft +, 250 ft +, 400 ft +, 500 ft +, 1,000 ft + |
Leveling | Self Leveling |
Accuracy | 1/8" At 100ft |
